Kona PZ-535L

Contact us for price

Why No Price?

Some of our manufacturers' internet policies will not permit us to list sale prices and some do not allow us to display pricing at all. On these items we ask that you either give us a call for a price or click the Get a Quote button and we can quickly email it to you. We apologize for the inconvenience and look forward to hearing from you!

Seats 3 Adults

5’4″ x 7′ x 34″

19 Jets

Or Call Us

(317) 773-3545


If you’re in the market for space saving spa that delivers big on relaxation and comfort, The Kona PZ-535L is for you. It offers an incredible hydrotherapy experience with a smaller footprint. The Kona is part of Cal Spas’ Patio Series lineup. It features a full size lounge seat, plus two bench seats, so it’s ideal for individuals or couples looking for a smaller hot tub.

The Kona measures 5’4”x7’x34” and has 35 total jets. Each seat has a unique jet configuration so you can tailor your hydrotherapy experience to your needs. The beautiful 5″ multi-colored LED light provide the peaceful ambience you’ll look enjoy as you relax.

This spa features an eliminator high performance pump and can be used with a standard 120V outlet or converted to be used with a 240V outlet. And the 5.5 KW (at 240V, or 1.5kW at 120V) titanium heater will keep your hot tub water hot all year round. The Cal Preferred cabinet walls are fully insulated for maximum heat retention and energy efficiency.

Controlling your spa is made easy with Cal Spas’ Balboa Equipment with Topside Control TP500. All the controls are right at your fingertips! Adjust the temperature, jets, and ambient lighting with just a touch of a button. With so much to offer, Kona will become your new favorite place to relax.


Seating Capacity

3 Person

Cal Spas Series

Patio Series

Seating Style

Lounge Seating


Cal Spas

Hot Tub Size

Less than 6'



Water Capacity

226 (855 L)

Weight (dry)

535 (243 kg)

Weight (filled)

2,423 (1,100 kg)

Jet Count



19 Exclusive Stainless Candy Cane Jets, 16 Air Injection Jets

Water Care Systems

Compatible with Bromine or Chlorine



Multi-color LED Lighting

5" Multi-Color LED Spa Light

Circulation Pump

1 x 1HP Turbo Charge Air Injection System, 1 x 2.0 BHP Eliminator High Performance Pump

Heater Output

1.5 kW at 120 Volts 5.5 kW at 240 volts

Control System

Balboa Equipment with Topside Control BP 501G1 TP500

Electrical Requirements


Gate Valve(s)


Air Venturi Valve


Filter Size

50 sq. ft. filter

Energy Efficiency

Thermo-Shield™ Insulation Side Panels and Thermo-Layer Floor with ABS Liner

Ozone System

Hydro Clear Ozonator (Optional)

Pressure Treated Cabinet



Cal Spas Premium Badge on Cabinet

Cabinet Type

Cal Preferred™ Vertical

Spa Shell Options

White Gloss

Cabinet and Step Colors

Smoke or Mist

Cover Colors

Brown or Gray


5 Years (Structural), 2 Years (Finish, Parts, Labor), 1 Year (Cabinet)

Patio Plus Series Spa Color Options

Cal Spas offers a comprehensive warranty on all of their hot tubs. Click the button below to view the Patio Plus Series Owner’s Manual, including warranty information.

Patio Plus Series Owner’s Manual
